Specifications · demo figures
Every number, in one place.
Avrel is a fictional product, so every figure here is a placeholder for yours. The groups below hold the usual questions a buyer asks before reserving.
01
02
03
04
05
06
07
08
A · Exploded view, seen from the front · scale 1 : 2 · demo
W 180 mm · H 150 mm
What each part is.
01
Headband
A flat strip with a fabric pad under its crown.
02
Pivots
An exposed barrel on each side; the cups fold flat.
03
Cups
Closed backs with one trim line and nothing else.
04
Cushions
Woven fabric over foam, the same cloth as the pad.
05
Drivers
One 40 mm driver per cup.
06
Dial
On the right rim: volume, pause, calls.
07
Battery
One cell inside the left cup.
08
Port
USB-C under the left cup.
Model
AVR-01
Title
Avrel headphone
Scale
1 : 2
Revision
0.9
Sheet
1 of 1
Finish
Slate
Drawn
Studio
Demo
Placeholder figures, replace
The table · demo figures
Six groups, no footnotes.
Each group is a block you can edit on the canvas: change a value, add a row, or remove a group.
Sound · demo
Driver
40 mm dynamic, one per cup
Response
20 Hz to 20 kHz
Impedance
32 ohm
Sensitivity
100 dB at 1 kHz
Isolation
Passive, closed back
Battery · demo
Playback
32 h at a normal volume
Full charge
2 h
Quick charge
10 min for 3 h
Charging
USB-C, under the left cup
Connection · demo
Wireless
Bluetooth 5.3
Codecs
SBC, AAC
Range
10 m, open space
Wired
3.5 mm cable, works with the battery flat
Size and weight · demo
Weight
255 g without the case
Folded
180 x 150 x 60 mm
Cup opening
60 x 40 mm
Band adjustment
30 mm each side
Controls · demo
Dial
Volume, pause, calls, on the right rim
Fold
Two pivots, cups fold flat
Finishes
Slate, Sand, Graphite
In the box · demo
Headphones
Avrel
Case
Folding
Cables
USB-C to USB-C 1.2 m, 3.5 mm audio
Paper
Quick guide
Seen enough?
Reserve a pair in under a minute. Demo form, nothing is sent.
